TD-M1-B
- - Multiple Unlock Methods: Supports Fingerprint, PIN Code, Dynamic Password, Tuya APP, IC Card, and Mechanical Key for versatile access control.
- - Sliding Door Support: Compatible with sliding doors, adaptation to various mortises, offering flexibility in installation.
- - High-Security Fingerprint Sensor: Utilizes a semiconductor fingerprint sensor with a False Recognition Rate of < 0.001% and False Rejection Rate of < 1.0%.
- - Large Capacity: Can store up to 100 fingerprints, 100 passwords, and 50 IC Cards, supporting MIFARE M1 card type.
- - APP Integration: Remote control via the Tuya App using Bluetooth 4.2 BLE connection.
- - Comprehensive Alarm System: Equipped with various door lock alarms and supports background push notifications for added security.
Specifications
| Unlock Methods | Fingerprint, PIN Code, Dynamic Password, Tuya APP, IC Card, Mechanical Key |
| Sliding Door | Support |
| Material | Aluminum |
| Lock Dimension | 28.6x315.6x22.8mm |
| Supported Mortise | 2585/2885/3085/3585/4085/4585/5085/6085, 2885/3585 multi-point, 2085/2885/3585 double-hook |
| Fingerprint Sensor Type | Semiconductor fingerprint sensor |
| Fingerprint Capacity | 100 |
| Password Capacity | 100 |
| IC Card Capacity | 50 |
| Supported IC Card Type | MIFARE M1 card |
| False Recognition Rate | < 0.001% |
| False Rejection Rate | < 1.0% |
| Supported Phone Systems | Android 5.0 or IOS7.0 and above |
| Tuya APP Connection | Bluetooth |
| Bluetooth Standard | Bluetooth 4.2 BLE |
| Connection Mode | Long connection (keep Bluetooth online) |
| Bluetooth Gateway | Support |
| Door Opening Record | Support |
| Alarm | All kinds of door lock alarm, support background push |
| Battery | 4pcs 1.5V AA alkaline dry batteries |
| Low Alarm Voltage | 4.6V |
| Voltage Range | 4.5V ~ 9V |
| Standby Current | 50μA |
| Working Current | ≤ 200mA |
| Unlocking Time | ≤ 1.5s |
| Operating Temperature Range | -20 ~ 60℃ |
| Relative Humidity | 40% ~ 90% (no gel cream) |
| Storage Environment | -40 ~ 85℃ |
| ESD(Contact Discharge) | 8KV (with lock case) |
| ESD(Air Discharge) | 15KV (with lock case) |
| Motor Drive | The output voltage is the supply voltage, and the current is ≤ 0.6A |
| Keypad Type | Capacitive touch keypad |
